Small Polycrystalline Solar Module

Polycrystalline small solar module 5W
12pcs x (77mmX31.2mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 10-12W
36pcs x (77mmX26mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 15W
36pcs x (77mmX39mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 20-25W
36pcs x (77mmX52mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 30-35W
36pcs x (77mmX78mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 40-50W
36pcs x (156mmX52mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 60W
72pcs x (156mmX31.2mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 70-75W
36pcs x (156mmX78mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 80-100W
72pcs x (156mmX52mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 105-125W
36pcs x (156mmX130mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 130-155W (4X9)
36pcs x (156mmX156mm), 4X9
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 130-155W (6X6)
36pcs x (156mmX156mm), 6X6
Max. power tolerance: -3%~+3%

Polycrystalline small solar module 50W
72pcs x (78mmX52mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 60W (6X12)
72pcs x (156mmX31.2mm), 6X12
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 70W
72pcs x (156mmX39mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 80-100W (6X12)
72pcs x (156mmX52mm), 6X12
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 105-115W
72pcs x (156mmX66mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 120-150W
72pcs x (156mmX78mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 160W
72pcs x (156mmX90mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 170-200W
72pcs x (156mmX104mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 210-230W
72pcs x (156mmX117mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 240-260W
72pcs x (156mmX130mm)
Max. power tolerance: -3%~+3%


Polycrystalline small solar module 265-310W
72pcs x (156mmX156mm)
Max. power tolerance: -3%~+3%

    Properties of the module

  • All of the materials used in our module have been certified by international standards
  • A fully automatic production line as well as comprehensive quality control and traceability system have been set for the solar cells and modules
  • The compressive strength of the module has passed the TUV certification (max load: 5400pa; max wind speed: 120km/h)
  • The monocrystalline module shows good performance in conditions of low sunlight intensity
  • The max power tolerance of the module is 3%

    Warranty period (25 years)

  • Warranty period for the solar module is 10 years
  • The output power of the module is committed to be no less than 90% of the peak value within 10 years, and no less than 80% within 25 years
